4. GENERAL DESCRIPTION
TOA's NX-100 Network Audio Adapter is specially developed to transmit high-quality audio signals and such
control data as serial data over IP networks such as LAN or Internet in real time.
[Audio Signal Flow Chart]
5. FEATURES
• Permits use of not only dedicated lines, but also the Internet, which greatly reduces operating costs when
transmitting audio signals to remote locations.
• Under peak conditions with no network delay, audio signals can be transmitted with a minimal delay of about
20 ms.
• Transmission of control data, such as contact and serial data, possible.
• Simultaneous bi-directional transmission of audio signals possible.
• Simultaneous transmission of audio signals to multiple locations (up to 4 locations for unicast*
1
streaming,
64 locations for multicast*
2
streaming) possible.
• Enables loss-free audio signal transmission even over congested networks such as the Internet.
• The entire system can be remotely operated or managed from a single PC (personal computer) using the
supplied software program.
• Because audio transmissions can be started and finished via the unit's contact inputs, systems can be
configured even without the use of a personal computer.
• Designed to operate on both AC and DC power sources.
*
1
UNICAST: A communications method used to transmit audio data to designated addresses in a matched
ratio of 1:1. Up to 4 channels can be simultaneously transmitted.
*
2
MULTICAST: A communications method used to simultaneously transmit a single audio data source to
multiple destinations.
