TOHATSU MFS 5 Service Manual

6
6-5
4st 4/5/6 2011
1-1 Drive Shaft Housing Ass'y (S) 1 For Transom "S"
1-2 Drive Shaft Housing Ass'y (L) 1 For Transom "L"
1-3 Drive Shaft Housing Ass'y (UL) 1 For Transom "UL"
2 Bushing Shift Lever 1
3 Exhaust Plug 1
4-1 Drive Shaft Bushing Ass'y 1 For Transom "L"
4-2 Drive Shaft Bushing Ass'y 1 For Transom "UL"
5-1 Drive Shaft Bushing 1 For Transom "L"
5-2 Drive Shaft Bushing 1 For Transom "UL"
6 Stopper Drive Shaft 1
7 Screw Pre-coated 5-25 2
8Washer 2
9 Screw 2 M5 L=10mm
10 Grommet Cam Rod 1
11 Dowel Pin 6-12 2
12 Bolt 1 M8 L=8mm
13 Gasket 8.1-15-1 1
14 Grommet 29.3 1
15 Bolt 6 M6 L=30mm
16 Drive Shaft Housing Gasket 1
17 Extension Housing 1
18 Bolt 1 M6 L=25mm
19 Washer 1
20 Stud Bolt 1 M8 L=25mm
21 Washer 1
22 Nut 1 M8
23-1 Shift Rod (S) 1 For Transom "S"
23-2 Shift Rod (L) 1 For Transom "L"
24 Shift Rod Lever 1
25 Pin Shift Lever 1
26 Split Pin 1
27 Shift Rod Joint Ass'y 1
28 Washer 1
29 Bolt 5-16 1 M6 L=16mm
30 Bolt 1 M4 L=16mm
31 Shift Lever 1
32 O-Ring 1.9-8.8 2
33 Ceramic Ball 7.7 1
34 Spring Shift Lever Stopper 1
Ref.
No.
Description RemarksQ'ty
Do not reuse.
Do not reuse.
Do not reuse.
MFS4-5-6Ech06110422.qxd 11.4.22 5:50 PM  ページ5
