TOHATSU MFS 5 Service Manual

7-3
4st 4/5/6 2011
7
1 Swivel Bracket A 1
2 Swivel Bracket B 1
3 Clamp Bracket (R) 1
4-1 Clamp Screw Ass'y 1 R
4-2 Clamp Screw Ass'y 1 L
5-1 Clamp Screw 1 R
5-2 Clamp Screw 1 L
6-1 Clamp Screw Handle 1 R
6-2 Clamp Screw Handle 1 L
7-1 Rivet 3-22 1 R
7-2 Rivet 3-22 1 L
8-1 Clamp Screw Pad 1 R
8-2 Clamp Screw Pad 1 L
9 Clamp Bracket (L) 1
10 Bolt 8-122 1
11 Nylon Nut 8P1.25 1 M8
12 Washer 1
13 Washer 8.5-28-1 2
14 Distance Plate Bracket 1
15 Screw 2 M6 L=12mm
16 Stern Bracket Spring 1
17 Screw 1 M4 L=6mm
18 Washer 4.3-16-1.5 1
19 Thrust Rod 1
20 Thrust Rod Spring 1
21 Bolt 4 M6 L=40mm
22 Thrust Bushing 1
23 Bushing Upper Steering 1
24 Bushing Lower Steering 1
25 Friction Band Ass'y 1
26 Thrust Plate (Lower) 2
27 Spring Co-Pilot 1
28 Wing Nut M6 1
29 Washer 6-16-1.5 1
30 Tilt Stopper Ass'y 1
31 Tilt Stopper Grip 1
32 Bushing Tilt Stopper 2
33 Setting Plate Tilt Stopper 1
34 Bolt 2 M6 L=12mm
35 Grease Fitting 2
36 Reverse Lock Arm 1
37 Bolt 2 M6 L=14mm
38 Reverse Lock Spring (R) 1
39 Reverse Lock Spring (L) 1
Ref.
No.
Description RemarksQ'ty
MFS4-5-6Ech07110422.qxd 11.4.22 5:55 PM  ページ3

TOHATSU MFS 5 Specifications

General

Brand	TOHATSU
Model	MFS 5
Category	Outboard Motor
Language	English
