TOHATSU TLDI MD 115A SERIES User Manual

3. Drive spring pin 7.
6-22
Lower Unit
TLDI 115A 2007
17) Assembly of Clutch Cam Parts
1. Attach O rings 1.9-6.8 2 and O ring 3.5-27.7 3 to cam
rod bushing 1.
2
1
3
OIL
GEARGEAR
GEAR
GREASE
OBMOBM
OBM
5
1
4
8
7
6
4
7
1
Spring Pin Tool B 8 :
P/N. 369-72218-0
CAUTION
Drive spring pin
7
so that it is flush with
clutch cam surface as shown.
16) Inspection of Clutch Cam
1. Check the part for wear and damage.
Replace if necessary.
Check especially for wear on the face a that
scrapes against push rod and flaws on the
circumference b.
a
b
2. Attach cam rod bushing 1, shift rod joint 5 and clutch
cam 6 to cam rod 4.
23 O Rings
Do not reuse.
7 Spring Pin
Do not reuse.
MD115Ach06E2校070604.qxd07.6.66:34PMページ22

TOHATSU TLDI MD 115A SERIES Specifications

General

Power Output	115 HP
Starting System	Electric
Lubrication	Oil Injection
Cooling	Water-cooled
Steering	Remote
Trim System	Power Trim and Tilt
Shaft Length	20" (508 mm)
Engine Type	2-Stroke
Ignition System	CDI
Fuel System	Direct Fuel Injection
Exhaust	Through Propeller
