3. INITIAL USE
Before using your TONE Touch 03
3.1 PLACE OF USE
Brewer should be installed only inside and
in a dry environment. Brewer should be
installed on a secure, level, surface capable
of fully supporting the weight of the brewer,
including the water retained in the brewer,
and any fully loaded dispenser(s) that may
be placed on the brewer.
▪ A potable water line (cold water) capable
of consistently supplying the required
minimum flow rate within the noted pressure
range is required at the install location.
▪ A grounded electrical connection
to a circuit that meets the electrical
specifications of the brewer and is protected
by the appropriate size and type of breaker is
required. See the supply cable specification
in chapter 3.3.
CAUTION
Power to brewer must be
off before proceeding with
plumbing installation.
CAUTION
Improper electrical
installation will damage
electronic components.
Damage caused by incorrect
electrical connections in not
covered by warranty.
3.2 PLUMBING CONNECTION
▪ The brewer must be rinsed after being
connected to the water supply line.
Remaining air in the system will be removed.
Otherwise it may lead to malfunctions and
noise in the housing. Follow instructions in
section Button functions.
▪ The pressure of the water line must be
within 1.5 bar – 3 bar.
▪ The installation of a water softening filter
system is mandatory for the use of TONE
equipment. Any violation of this regulation
will lead to a complete loss of any warranty
on the complete system.
▪ The brewer has a descaling tracking
function available. Follow the instrcutions
on page 19.
3.3 ELECTRICAL CONNECTION
WARNING
The brewer must be
disconnected from the
power source until specified
in INITIAL SET-UP.
CAUTION
Improper electrical
installation will damage
electronic components.
Damage caused by incorrect
electrical connections is not
covered by warranty.
▪ An electrician must provide electrical
service as specified in conformance with all
local, state and federal electrical codes.
▪ Recommended backup fuse: 16A
▪ Recommended electrical supply cable:
3x2.50 mm
2
or 3x13 AWG, according to local
regulations
▪ The electrical ratings can be found on the
type plate which you will find on the device.
▪ Use a voltmeter to check the voltage
and color coding of each conductor at the
electrical source.
▪ Ensure power switch on rear of brewer
is in the off position. Connect brewer to
power source and verify voltage at terminal
block. Replace rear panel and top cover. If
plumbing has been hooked up, brewer is
ready for Initial Set-Up. If not, disconnect
brewer from power source.
