Instructions for mounting the TONE Filter Stand
Version A
“Blackbox without a groove”
1. Remove the black lid from the black box (No.1)
2. Remove the little black cap (No.2)
3. Take away the little pin out of the srew (No.3) (pin is only needed for Version B)
4. Fix the screw (No.3) with the washer and the 22mm nut (No.4)
5. Before you tight it all the way orientate the screw with the alignment tool and the
cylinder head screw (No.5)
6. Tight the nut firmly (No.4,
note that the screw does not rotate in the process)
7. Loose the alignment tool and store it in a known place
8. Insert the filter stand and fasten it with the knurled screw in the hole provided
(No.6)
9. Choose the desired height for both platforms (No.7)
10. Brew some amazing coffee
Version B “Blackbox with a groove”
1. Remove the black lid from the black box (No.1)
2. Remove the little black cap (No.2)
3.
Fix the screw with the washer and the 22mm nut (No.4)
4. Before you tight it all the way make sure the small pin (No.3) is located in the
provided groove
5. Tight the nut firmly (No.4, note that the screw does not rotate in the process)
6. Insert the filter stand and fasten it with the knurled screw in the hole provided
(No.6)
7. Choose the desired height for both platforms (No.7)
8. Brew some amazing coffe
e
