INSTRUCTIONS FOR MOUNTING THE FILTER STAND
This manual is only required if you install the option “Filter Stand” later to the purchase of the
TOUCH 03
Version A “Blackbox without a groove”
▪ Remove the black lid from the black box (No.1)
▪ Remove the little black cap (No.2)
▪ Take away the little pin out of the srew (No.3) (pin is only needed for Version B)
▪ Fix the screw (No.3) with the washer and the 22mm nut (No.4)
▪ Before you tight it all the way orientate the screw with the alignment tool and the cylinder
head screw (No.5)
▪ Tight the nut firmly (No.4, note that the screw does not rotate in the process)
▪ Loose the alignment tool and store it in a known place
▪ Insert the filter stand and fasten it with the knurled screw in the hole provided (No.6)
▪ Choose the desired height for both platforms (No.7)
▪ Brew some amazing coffee
Version B “Blackbox with a groove”
▪ Remove the black lid from the black box (No.1)
▪ Remove the little black cap (No.2)
▪ Fix the screw with the washer and the 22mm nut (No.4)
▪ Before you tight it all the way make sure the small pin (No.3) is located in the provided groove
▪ Tight the nut firmly (No.4, note that the screw does not rotate in the process)
▪ Insert the filter stand and fasten it with the knurled screw in the hole provided (No.6)
▪ Choose the desired height for both platforms (No.7)
▪ Brew some amazing coffee
ATTENTION:
Make sure that the cable connections will not be damaged during the assembling.
Be careful during the entire process.
OPTIONAL FILTER STAND
