9
5 ENTER/REC button
This button is used to switch an effect on/off,
or to start recording in Phrase Trainer mode.
6 Input level switch
Use this to adjust the input level (appropriate
for the output level of your guitar).
7 Amp Modeling selector
Select the type of amp modeling.
8 ▲/▼ buttons
Use these buttons to select programs and edit
effects,
9 OUTPUT jack
Connect this jack to your guitar amp or head-
phones etc.
0 INPUT jack
Connect your guitar to this jack.
A AUX jack (stereo)
Connect this jack to a CD player or other au-
dio source.
B DC4.5V
The separately sold AC adapter (DC4.5V
) should be connected here.
C √/® buttons
Use these buttons to select the parameter that
you wish to edit, and to operate the Phrase
Trainer function.
D Power switch/Backlight switch
This switch turns the power on/off, and also
turns the backlight on/off.
If you are operating the PX4 on batteries, the
operating time will be shorter if you turn on the
infrared transmitter or backlight.
E Value dial
Use this to adjust master level, edit effects,
and select programs.
F TAP button
You can set the Delay Time by pressing this
button twice at the desired tempo of delay. In
Rhythm & Bass mode, you can set the tempo
of the rhythm in the same way.
G Mode buttons
Use these buttons to enter Rhythm & Bass,
Phrase Trainer, or AUX Pitch modes.
