INSTALLATION AND USER MANUAL
3. Installing the Electric Fence Energizer
4.1 Connecting to the power source
The Electric Fence Energizer can operate using mains power, 12 v deep cycle lead-acid/gel battery
or solar and lead-acid/gel battery.
Mains power
1. Attach the mains power adaptor to the Energizer
– insertion point on reverse side of unit – and
plug into the mains power socket
2. DO NOT turn the mains power on until the
powered fence system is fully constructed and
you are ready to use it
Battery (not included)
1. Always use a 12 v deep cycle lead-acid/gel battery
2. Site the battery in a well-ventilated area
3. Attach the battery cable to the Energizer – insertion
point on the reverse of the unit
4. Connect the RED clip to the POSITIVE (+) terminal of
the external battery
5. Connect the BLACK clip to the NEGATIVE (-)
terminal of the external battery
Battery: Lead-acid or other kind of battery with voltage
more than 12 v.
Solar/battery (not included)
1. The Electric Fence Energizer is compatible
with a minimum 40 w solar fence panel and a
12 v deep cycle lead-acid/gel battery
2. Set up the solar panel as per the instructions
enclosed with it using the appropriate
regulator. If you bought your solar panel it
will include the correct charging regulator.
3. Set up the 12 v deep cycle lead-acid/gel
battery as per above instructions for Battery
Solar panel: voltage more than 12 v solar controller or
battery is necessary)
