22. Technical data
Operating voltage: 2 x 1.5 V/DC battery type AA
Measuring range: 0.05 – 70 m
Resolution: 0.001
Accuracy: ±1.5 mm
Laser class: 2
Laser wavelength: 650 nm
Laser output power: <1 mW
Automatic power-off: 30 seconds (laser)
180 seconds (display)
Operating temperature: -5 to +40 ºC, <70 % RH
Storage temperature: -20 to +60 ºC, <90 % RH
Dim. (W x H x D): 55 x 32 x 120 mm
Weight: 169 g
The working range and accuracy depends on how well the laser light is
reected from the surface of the target and with the increased brightness
of the laser pointer to the ambient light intensity. An unfavorable
condition will shorten the operating range with approximately ten
millimeters error.
