Toolots GB4232 - Main Application and Technical Data; Main Technical Data; Machine Rigger and Installation; Rigger

1
Ⅰ
Main A
pplication
Band sawing machine is a continuous feeding equipment, mainly for the carbon steel,
low alloy steel, high-alloy steel, special alloy steel, stainless steel, acid-proof steel
and other metal materials. Can cut non-ferrous metals and non-metallic materials if
replace proper-able Saw Blades.
ⅡMain Technical Data
Form 1
Model
GB4232
Cutting Range(Inch)
Φ12 19/32 (W) 19 11/16x(H)12 19/32
Saw Blade Specification
LxWxH (Inch)
168 57/64 * 1 11/32 * 3/64
Cutting Speed (inch/min)
1023 5/8、1614 11/64、2047 1/4、2913 25/64
Voltage (V~HZ)
230V~60HZ
Main motor Power (kw)
3~4P
Hydraulic motor power (kw)
3/4
Cooling Pump Power (kw)
1/25
Fuel tank capacity (L)
40
Coolant volume (L)
30
Machine Dimensions LxWxH (Inch)
84 16/25x43 3/100x53 93/100
Ⅲ
Machine Rigger and Installation
1. Rigger
It should make full use of lifting equipment when handling machine, wire
connecting methods shown in Figure 1. Wood, rubber or other soft objects should be
used in the line of the vehicle-wire touching in order to avoid bumps machine and
painting. .
2.Box Opening
Check box when opening csuch as packing list indicating the volume of goods.
3.Installation
