16) Avoid overexposure to fumes and gases. Always keep your head out of the fumes.
Do not breathe the fumes. Use enough ventilation or exhaust, or both, to keep
fumes and gases from your breathing zone and general area.
17) Live torch when Trigger is pressed. Keep Torch away from people and flammables
before touching Trigger.
18) Turn off, unplug, and discharge electrode to ground before perform-ing any
inspection, maintenance, or cleaning.
19) Use only compressed air at between 0.4 and 0.5 MPA. Never u
se oxygen, carbon
diox
ide, combustible gases or any bottled gas as an air source for the Machine.
Such gases are capable of explosion and serious injury to people.
20) The warnings, precautions, and instructions discussed in this instruction manual
cannot cover all possible conditions and situations that may occur. It must be
understood by the operator that common sense and caution are factors which
cannot be built into this product, but must be supplied by the operator.
SPECIFICATIONS
INITIAL SETTING UP INSTRUCTION
4
Input Voltage 120VAC / 60HZ
Current Input 23.5A
Output Range 30-125A
Rated Duty Cycle 30%@90A
Maximum OCV 45.5 V
Wire Speed 0-120 IPM
Welding Wire Capacity 0.030/ 0.035” Flux Cored
Wire Spool Capacity 2 LB Spool
Read the entire Important Safety Information section at the beginning of this manual
including all text under subheadings therein before set up or use of this product.
To prevent serious injury from accidental operation:
Turn the Power Switch of the machine to its “OFF” position and unplug it from its electrical
outlet before assembling or making any adjustments to the machine.
Note: For additional information regarding the parts listed in the following pages,
refer to the Assembly Diagram near the end of this manual.
1. Assembly
1) Unpack and make sure all the items in good condition. When you receive the
parcel, check it carefully from the packing list to make sure no damage due to
shipping. If there is any damage happened, inform the carrier immediately to
claim before installing. Complete the information and damage details in the
order’s returns and refund of the Amazon order in that case. Care the safety to
avoid damaging the machine
when using bars, hammers, etc.
