- 5 -
numbers stamped on them, but in some cases the
number is located alongside the parts or only on the
die drawings in the manual. Do not remove the die-cut
parts until instructed to do so. If a part is difficult to
remove, don’t force it out but cut around it with a hobby
knife and a #11 blade. After you remove the parts from
their die sheets, lightly sand the edges to remove
slivers or die-cutting irregularities. Save some of the
larger scraps of wood.
3. Separate the parts into groups such as stab, fin,
wing, and fuse. Store smaller parts in zipper-top
food storage bags.
TYPES OF WOOD
BALSA BASSWOOD PLYWOOD
COMMON ABBREVIATIONS
deg. = Degrees
Elev = Elevator
Fuse = Fuselage
LE = Leading Edge (front)
LG = Landing Gear
Lt = Left
Ply = Plywood
Rt = Right
Stab = Stabilizer
TE = Trailing Edge (rear)
" = Inches
METRIC CONVERSIONS
1" = 25.4mm (conversion factor)
1/64" = .4mm
1/32" = .8mm
1/16" = 1.6mm
3/32" = 2.4mm
1/8" = 3.2mm
5/32" = 4mm
3/16" = 4.8mm
1/4" = 6.4mm
3/8" = 9.5mm
1/2" = 12.7mm
5/8" = 15.9mm
3/4" = 19mm
1" = 25.4mm
2" = 50.8mm
3" = 76.2mm
6" = 152.4mm
12" = 304.8mm
15" = 381mm
18" = 457.2mm
21" = 533.4mm
24" = 609.6mm
30" = 762mm
36" = 914.4mm
