Page8
Visitwww.solutions.norac.caformoresystem
installationandtroubleshootinginfo.
5.3. RainflapInstallation

Ifthekitincludesrainflaps,installthemasshownbelowONLYonbracketsthatfaceupwardwhenthesprayer
isintransportmode.
1. Insertonesideoftherainflaprodintothepre‐benthingetabonthesensorbracket.(Figure6)

Figure6:RainflapRodinPre‐BentHingeTab
2. Aligntheothersideoftherainflaprodwiththeunbenthingetab.(Figure7)

Figure7:AlignRainflapRod
3. Bendthehingetabinwardovertherainflaproduntilthehingetabfitssecurelyinthedetentgrooveon
thebacksideofthesensorbracket.(Figure8)

Figure8:BendRainflapHingeTab
4. Ensuretherainflapactuatessmoothlywhenthebracketisturnedupsidedownandreturnstotheopen
positionwhenthesensorbracketisreturnedtoitsoperatingposition(sensorpointingdownwardstoward
theground).
