22
5 Measure the distance between the first and second marks on each wall.
If the difference between each set of marks is less than 4mm (5/32 of an
inch), no error exists.
*If the difference value is greater than 4mm(5/32 inch), contact your
Topcon dealer.
Cone error
Datum position
Wall A
Wall B
Wall A
Approx. 40m
Wall B
