53
MAINTENANCE
MAINTENANCE
DAILY CHECKUPS
• Before using this instrument, always inspect it.
• Each time you use this instrument, clean it according to "CLEANING" on page 60.
• Dust is a formidable foe to the instrument.
• To ensure the production of fine images, care should be taken not to allow fingerprints and/or
dirt on the objective lens.
• When not in use, be sure to cap the objective lens and cover the instrument with the dust
cover.
• Before using the instrument, check if the objective lens is clean. If the objective lens is
stained, clean it following the instructions for "CLEANING THE OBJECTIVE LENS" on page
60.
• When not in use, always turn the OFF.
ORDERING CONSUMABLES
• When ordering consumables and spare parts, contact your dealer or TOPCON (see the back
cover) and tell them the article name, article code and quantity.
MAINTENANCE BY THE DEALER
CAUTION
To prevent damage and injuries, do not install the instrument on an
uneven, unsteady or sloped surface.
Article name Article code Article name Article code
Illumination lamp 40535 40200 Fuse 15A 125V (for 100V/120V) T24000086A
Xenon lamp 40413 16200 8A 250V (for 230V) T24000085A
Chinrest tissue paper 40310 4082
Dust cover 40488 1007
Item Inspection interval Details
Cleaning each unit Within 12 months from
the last maintenance
• Cleaning the external section
• Cleaning the optical system
• Cleaning the base unit
Checking the operation Within 12 months from
the last maintenance
• Operation of the main body
• Operation of the switches
Checking photography Within 12 months from
the last maintenance
• Focus, flare, center ghost and dust
• Checking the xenon light intensity
(by the special tool)
POWER SWITCH
To Next Page
