Topdon BT100W - Cranking Test Procedure

5) Test result will show as below (See Figure 4.1.5) (if there is any suggestion, please
follow accordingly):
Figure 4.1.5
2. Cranking Test
Note:
1) Turn off the engine and all accessories.
2) The test only applies to 12V lead-acid batteries.
Test Steps:
1) Select "2. Cranking Test" and press "Enter".
Figure 4.2.1
Main Menu
1.Battery Test
2.Cranking Test
3.Charging Test
4.Review Data
5.Language
6.About
EN I 14
Setting Rate
GOOD BATTERY
250CCA
12.95V
11.96mΩ
300A
Healthy
:
60%
Charge
:
98%
Internal R =
Rated
:
