3. Charging Test
Note:
1) The test only applies to 12V lead-acid batteries.
Test Steps:
1) Select "3. Charging Test" and press "Enter".
Figure 4.2.2 Figure 4.2.3
Cranking Test Cranking Test
2) Start the engine as prompted and the test result will show as below.
Refer to the table below to better understand the test result.
Item
1
2
3
Cranking Voltage (V)
V < 9.6
9.6 ≤ V < 10.7
V ≥ 10.7
Conclusion
Cranking Low
Normal
Good
START ENGINE
TIME
VOLTAGE
NORMAL
1024ms
10.12V
30
EN I 15
