EN I 16
Figure 4.3.1
Main Menu
1.Battery Test
2.Cranking Test
3.Charging Test
4.Review Data
5.Language
6.About
2) Start the engine as prompted and press "Enter" to start the ripple test.
Figure 4.3.2 Figure 4.3.3
Charging Test RIPPLE TEST
Please start engine,
Press ENTER to continue.
12.98V
