- 43 -
6. Light spots on the right sides
of images
2) Move the objective lens in the
left-right direction
3) Move the objective lens in the
left-right direction
8 Transport and storage
During the transportation, proper measures shall be taken to protect this equipment from
moisture, upside down and violent vibration.
This equipment shall be stored at the well-ventilated room with the relative moisture no
higher than 93%, ambient temperature being -40℃ - +55℃and free of corrosive gases.
Please require workers to lift up the equipment and then move it in case of short-distance
movement. In case of long-distance movement, please repack it in the original box and then
move it.
9 Environmental protection
During the normal use and maintenance of the equipment, the replaced components or
other wastes should be properly disposed according to local laws and regulations and should
not be discarded arbitrarily. The equipment should be recycled in accordance with the
requirements of local laws and regulations at the end of the service life, to avoid causing
environmental pollution.
10 Electro-magnetic compatibility
The design of RetiCam 3100 meets the specifications of EMC standards on the medical electronic
equipment -- IEC 60601-1-2 (EN 60601-1-2) Standards, and the equipment shall be installed and
used according to the following EMC declaration.
• All parameters set can display normally as expected, all functional keys can work well, and there
is no wrong order during operation.
• The chin rest and machine can work well, free from any unexpected movement.
Turning on/off the power supply of this equipment may intervene other equipment. In case of this
condition, please adopt the following solutions:
