TorcUP EP500 - Page 15

COMMON COMPONENTS
EP1000
Common components
used in pumps
EP1000 Torque Wrench
Power Pump
NOTES :
REBUILD KIT ( * = COMPONENTS) -- PART # 54488
ITEM # DESCRIPTION PART # PART # QTY. ITEM # DESCRIPTION PART # PART # QTY.
02 PUMP ASM. 1.00 29 HEAVY HEX JAM NUT 1/4-20 69234 69234 2.00
03 RESERVOIR 1.00 30 BHCS 10-24 x 3/8 LG 69236 69236 4.00
04 RESERVOIR GASKET 1.00 30 BHCS 10-24 x 3/8 LG 69236 69236 4.00
05 BREATHER VENT 3/8" NPT 46348 46348 1.00 35 DECAL 5.71" x 1.15" 46355 46355 2.00
06 PIPE PLUG 1/4" W/ COATING 46510 46510 1.00 37 QUICK DISCON. FLAG BLUE 44491 44491 2.00
07 SAE #12 HEX PLUG WITH PT 46118 46118 1.00 42 HOLE PLUG 1/4" 46405 46405 4.00
08 HHC
S 1/4-20 X .75 PLT 65891 65891 14.00 43 SPACER 1" 69353 69759 2.00
09 SEALING WASHER 65892 65892 14.00 44 HHCS 1/4-20 X 1.50 84417 87260 2.00
10 G5 RESERVOIR DECAL 46052 46052 2.00 45 WASHER 1/4" SS 88429 88429 2.00
11 LABEL SAFE USE ELEC 68068 68068 1.00 46 COIL 115V WITH DIN CONNECTOR 46294 46324 1.00
12 BLANK DECAL 3 X 4 87305 87305 1.00 52 SIGHT GAUGE 46009 46009 1.00
13 MANIFOLD ASM. 1.00 57 1/4 IN NIPPLE 4100067 4100067 1.00
14 VALVE GASKET 69242 6
9242 1.00 58 1/4" NIPPLE CT210 CT210 1.00
15 SHCS 3/8-16 X 2 3/4 99921 99921 3.00 59 1/4" SELF-LOCKING COUPLER 45765 45765 1.00
16 ADAPTER ASSY. 68963 68963 1.00 62 GAUGE SHROUD ASSEMBLY 46474 46474 1.00
17 HEX PIPE PLUG 3/8" W/ COATING 46513 46513 1.00 68 VELCRO STRAP 1x14 46310 46310 1.00
19 VALVE ASM. 2P/4W 1.00 70 GASKET-MOTOR 1.00
20 SHCS 3/8-16 X 3 1/2 88363 88363 4.00 71 PUMP GASKET G5 1.00
21 LOCK WASHER 3/8 93943 93943 2.00 73 COVER PLATE 1.00
21 LOCK WASHER 3/8 93943 93943 4.00 74 PIN,DOWEL 3/16 1" LONG 69026 69026 1.00
22 ROLL PIN 1/8 X 3/8 LG 561604 561604 1.00 75 SHCS 3/8-16 X 1 93594 93594 2.00
24 MAGNET 66021 66021 1.00 76 1 1/2HP, PM MOTOR 68376 68403 1.00
25 MOTOR SHROUD W/ HANDLE 45534 45534 1.00 78 FHCS 1/4-28 x 0.50 LONG 46279 46279 4.00
27 DECAL OVERLAY 46539 46539 1.00
28 BRACKET ASM - CIRCUIT BOARD 1.00
SEE PAGE 21-22
*
*
SEE PAGE 23
SEE PAGE 19
SEE PAGE 16
SEE PAGE 23
*
SEE PAGE 20
15
14/37
