TorcUP EP500 - Table of Contents

Operational and Maintenance Manual for TorcUP
EP500 & EP1000 Torque Wrench Pump
TorcUP Inc. is not responsible for customer modication of tools for applications on
which TorcUP Inc. was not consulted.
IMPORTANT SAFETY INFORMATION ENCLOSED.
READ THIS MANUAL BEFORE OPERATING PUMP.
IT IS THE RESPONSIBILITY OF THE EMPLOYER TO PLACE THE INFORMATION IN THIS
MANUAL INTO THE HANDS OF THE OPERATOR.
FAILURE TO OBSERVE THE FOLLOWING WARNINGS COULD RESULT IN INJURY.
The use of other than genuine TorcUP replacement parts may result in safety
hazards, decreased tool performance, and increased maintenance, and may
invalidate all warranties. Repairs should be made only by authorized
personnel. Consult your nearest TorcUP Authorized Service Center.
Refer All Communications to the Nearest TorcUP Ofce or Distributor.
For Technical Support & Information Contact:
TorcUP Inc.
1025 Conroy Place, Easton, PA 18040 USA
Phone: +1 610-250-5800 Fax:+1 610-250-2700
email: sales@torcup.com
CONTENTS
TorcUP has taken every care in preparing this Operational Manual that is intended as a technical guideline only. TorcUP
accepts no liability in relation to any use or reliance made of any information in this Operational Manual. All information,
illustrations and specications in this Operational Manual are based on the latest information available at the time of publica-
tion. The right is reserved to make changes at any time without notice. Equipment operators and installers shall be respon-
sible for ensuring that a safe working environment and safe systems of work are in place before operating the equipment.
Version 1: 2013 April
Category Page # Category Page #
Manual Index 1 Control Valves 8
General Warnings 2 Power Control Switches 8
Safe and Correct Use 3-5 Pressure Torque Setting 9
Warranty Statement 4 Completing the job 9
Working Pressure 5 Periodic Maintenance 9
Install Vent Plug 5 Oil Level 10
Adding Oil 5 Oil Intake Screen 10
General Safety 5 Oil Flushing 10
Technical Specications 6 Troubleshooting 11
Install Hydraulic Connections
6 EP1000 Parts Index 12
Electrical 7 EP500 Parts Index 23
Connecting Tools 7 Pendant 37
Initial Startup 7
Pump Mounting 8
EP500 EP1000
Shown with
optional quad kit
1/37
