(46336) PISTON BLK ASM.
(43766) UNLOADING PISTON ASM.
ITEM # DESCRITPION PART # QTY.
01 UNLOAD PISTON 43765 1.00
02 O RING 1/4X3/8 1.00
03 BACK-UP WASHER TEF 43768 1.00
04 DOWEL PIN 1/8X3/4 LG 43686 1.00
(45820) ECCEMTRIC SHAFT ASM.
ITEM # DESCRIPTION PART # QTY.
01 ECCENTRIC SHAFT 5/8" 45819 1.00
02 ECCENTRIC RING 45907 1.00
03 ROLL BEARING 1 1/8x1 3/8x3/4 WIDE 45926 1.00
04 RETAINING RING EXTERNAL 1 1/8" 45931 1.00
05 THRUST WASHER 68026 2.00
ITEM # DESCRIPTION PART # QTY.
01 GEN II PISTON BLOCK 45539 1.00
02 BALL 1/8" 90906 2.00
03 SPRING 66042 1.00
04 BALL STOP 68810 1.00
05 BALL RETAINER 66043 1.00
06 INTAKE SEAT 66046 1.00
07 GASKET 25/64X19/32 1.00
08 PLUG PISTON BLOCK 68825 1.00
09 GASKET 29/64 X 5/8 1.00
10 ADAPTOR .255 DIA. 68909 1.00
11 SPRING, PISTON 68340 1.00
12 PISTON .255 DIA. 68222 1.00
*
*
*
REBUILD KIT ( * = COMPONENTS) -- PART # 54488
SUB PUMP ASSEMBLY
EP1000
(45820) ECCENTRIC SHAFT ASM.
(46336) PISTON BLK ASM.
(43766) UNLOADING PISTON ASM.
18/37
