30
TX-16 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-16-L01- #* 1
2 Side Plate - Right TX-16-L02- #* 1
3 Drive Plate TX-16-L03- #* 1
4 Drive Pin TX-16-L05 1
5 Drive Pin Spring TX-16-L07 1
6 Ratchet TX-16-L09- #* 1
7 Drive Segment TX-16-L11- #* 1
8 Upper Spacer TX-16-L13 1
9 Middle Spacer TX-16-L14- #* 1
10 Lower Spacer TX-16-L15- #* 1
11 Spacer Pin TX-16-L17 2
12 Sideplate Sleeve TX-16-L19- #* 2
13 Shroud TX-16-L21 1
14 Segment Spring TX-16-L25 1
15 Upper Spacer Screw TX-16-L27 4
16 Lower Spacer Screw TX-16-L29 4
17 Shroud Screw TX-16-L31 2
18 Dr. Pin Spring Roll Pin TX-16-L33 1
19 Spacer Roll Pin TX-16-L35 1
*part number is dependent upon ratchet link size
