TorcUP TX-32 - TX-4 Series Link

26
TX-4 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-4-L01- #* 1
2 Side Plate - Right TX-4-L02- #* 1
3 Drive Plate TX-4-L03- #* 1
4 Drive Pin TX-4-L05 1
5 Drive Pin Spring TX-4-L07 1
6 Ratchet TX-4-L09- #* 1
7 Drive Segment TX-4-L11- #* 1
8 Upper Spacer TX-4-L13- #* 1
10 Lower Spacer TX-4-L15- #* 1
11 Spacer Pin TX-4-L17 2
12 Sideplate Sleeve TX-4-L19- #* 2
13 Shroud TX-4-L21 1
14 Segment Spring TX-4-L25 1
15 Upper Spacer Screw TX-4-L27 4
16 Lower Spacer Screw TX-4-L29 4
17 Shroud Screw TX-4-L31 2
18 Dr. Pin Spring Roll Pin TX-4-L33 1
*part number is dependent upon ratchet link size
