28
TX-8 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-8-L01- #* 1
2 Side Plate - Right TX-8-L02- #* 1
3 Drive Plate TX-8-L03- #* 1
4 Drive Pin TX-8-L05 1
5 Drive Pin Spring TX-8-L07 1
6 Ratchet TX-8-L09- #* 1
7 Drive Segment TX-8-L11- #* 1
8 Upper Spacer TX-8-L13- #* 1
10 Lower Spacer TX-8-L15- #* 1
11 Spacer Pin TX-8-L17 2
12 Sideplate Sleeve TX-8-L19- #* 2
13 Shroud TX-8-L21- #* 1
14 Segment Spring TX-8-L25 1
15 Upper Spacer Screw TX-8-L27 4
16 Lower Spacer Screw TX-8-L29 4
17 Shroud Screw TX-8-L31 2
18 Dr. Pin Spring Roll Pin TX-8-L33 1
*part number is dependent upon ratchet link size
