TX-2 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-2-L01- #* 1
2 Side Plate - Right TX-2-L02- #* 1
3 Drive Plate TX-2-L03- #* 1
4 Drive Pin TX-2-L05 1
5 Drive Pin Spring TX-2-L07 1
6 Ratchet TX-2-L09- #* 1
7 Drive Segment TX-2-L11- #* 1
8 Upper Spacer TX-2-L13- #* 1
10 Lower Spacer TX-2-L15- #* 1
11 Spacer Pin TX-2-L17 2
12 Sideplate Sleeve TX-2-L19- #* 2
13 Shroud TX-2-L21 1
14 Segment Spring TX-2-L25 1
15 Upper Spacer Screw TX-2-L27 4
16 Lower Spacer Screw TX-2-L29 4
17 Shroud Screw TX-2-L31 2
18 Dr. Pin Spring Roll Pin TX-2-L33 1
*part number is dependent upon ratchet link size
