22
TX-1 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-1-L01- #* 1
2 Side Plate - Right TX-1-L02- #* 1
3 Drive Plate TX-1-L03- #* 1
4 Drive Pin TX-1-L05 1
5 Drive Pin Spring TX-1-L07 1
6 Ratchet TX-1-L09- #* 1
7 Drive Segment TX-1-L11- #* 1
11 Spacer Pin TX-1-L17 3
12 Sideplate Sleeves TX-1-L19- #* 2
14 Segment Spring TX-1-L25 1
15 Side Plate Screws TX-1-L29 3
16 Dr. Pin Spring Roll Pin TX-1-L33 1
*part number is dependent upon ratchet link size
