TXU-8 Cylinder Swivel Low Prole Hydraulic Torque Wrench
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Housing TXU-8-C01 1
2 Piston TX-8-C03 1
6 Slider TX-8-C09 2
7 End Cap TXU-8-C11 1
8 Retaining Ring TX-8-C13 2
9 Link Pin TX-8-C15 1
10 End Cover TXU-8-C17 1
11 End Cover Screw TX-8-C23 1
12 Slider Pin TX-8-C27 1
13 End Plug Seal TX-8-C29 1
14 Rod Seal TX-8-C31 1
16 Piston Seal TX-8-C33 1
17 Cylinder Gland TX-8-C51 1
18 Link Retaining Spring TX-8-C53 1
19 Uniswivel Assembly USL-00 1
20 Uniswivel Post Screw USL-23 4
21 Male 1/4” NPT to Male 1/4” NPT F004004 1
22 Male Coupler HC-M-100 1
23 Female Coupler HC-F-400 1
40 Seal Insertion Tool ATX-8-ST
41 Gland Removal Tool ATX-8-GW
