20
TXU-4 Series Link
Part Numbers for Ordering
ITEM NAME PART # QTY.
1 Side Plate - Left TX-4-L01-#* 1
2 Side Plate - Right TX-4-L02-#* 1
3 Drive Plate TX-4-L03-#* 1
4 Drive Pin TX-4-L05 1
5 Drive Pin Spring TX-4-L07 1
6 Ratchet TX-4-L09-#* 1
7 Drive Segment TX-4-L11-#* 1
8 Upper Spacer TX-4-L13-#* 1
10 Lower Spacer TX-4-L15-#* 1
11 Spacer Pin TX-4-L17 2
12 Sideplate Sleeve TX-4-L19-#* 2
13 Shroud TX-4-L21 1
14 Segment Spring TX-4-L25 1
15 Upper Spacer Screw TX-4-L27 4
16 Lower Spacer Screw TX-4-L29 4
17 Shroud Screw TX-4-L31 2
18 Drive Pin Spring Roll Pin TX-4-L33 1
*part number is dependent upon ratchet link size
