48 R-500/R-700
Technical data
Technical data
The drives of the R-500/R-700 series are suitable for the following doors:
Canopy/non-swinging doors, double wing doors, swing doors/tilting doors, sectional doors/side section doors
Model Specifi cations R-500 R-700
Max. door size 9 m 13 m
Max. weight 120 kg 140 kg
Operator type R-500 R-700
Rated load capacity 150 N 210 N
Max. load 500 N 700 N
Connection values 230 V / 50 Hz
Power input:
Standby < 4 W
Max. operation 160 W
Cycles 3/h
Lighting LED 0,4 W
Safety according to EN13849-1:
Input STOP A Cat. 2 / PLC
Input STOP B Cat. 2 / PLC
internal force limit Cat. 2 / PLC
Temperature range
- 20°C
+ 60°C
Protection class IP20, only for dry rooms
Volume ≤ 70 dB (A)
Manufacturer: TORMATIC
Eisenhüttenweg 6
44145 Dortmund
Germany
www.tormatic.de
Disposal
Dispose of the product according to the laws and regulations of the respective country of use.
