TORNADO
USE AND MAINTENANCE MANUAL UPRIGHT DISPLAY CABINETS
428000393
237
C5 Electronic control board S1 Temperature probe
I1 Cabinet switch U1 Compressor
I2 Light switch U2 Condenser fan
L1 Magnetic ballast U3 Evaporator fan
L5 Fluorescent tube T8 U4 Cleaning fan
R2 Drip defrosting heating resistor U8 Starter
R3 Outside perimeter heating resistor
R19 Drip tray heating resistor
Attachment 2 - WIRING DIAGRAM - 412113870200
