6
TECHNICAL DESCRIPTION
Cleaning width mm/in. 430/17
Squeegee width /in.mm 510/20
Battery voltage V 24
Battery capacity Ah 5 34
Power rating W/A 670/28
Working capacity, up to sqm/h/sqft/hr 1505/16,200
Brush diameter mm/in. 430/17
Brush rpm rpm 155
Brush pressure kg/lbs. 35/77
Suction vacuum mbar/in. water lift 83/33
Type of drive semi autom.
Maximum gradient % 2
Capacity solution tank l/gal. 22/6
Capacity recovery tank l/gal. 22/6
Machine length (min) mm/in. 793/31
Machine height mm/in. 603/24
Machine width mm/in. 518/21
Machine weight (empty, with batteries) kg/lbs. 86,5/191
Weight of the batteries kg/lbs. 30/66
Recharging time max h 10
Battery compartment (L x W x H) mm/in. 346 x 207 x 21013.6 x 8 x 8
Acoustic pressure level (in conformity
with EN 604¬_01)
dB (A) <70
Class III
Protection level IP X3
Battery charger voltage V ~ 120-230
Battery charger frequency Hz 50-60
Battery charger class I
