Release the pedal handle lightly with your foot (1), pull back the handle (2) to start the
motor. The brushes and the drum starts rotating. Pulling the handle further without
pressing the pedal, lowers the machine and engages the rotating brushes onto the
oor. To stop working, take the handle to the vertical position.
1
2
OFFON
BEFORE
RESET
WAIT
SECONDS
30
!
PRESS
On/O Control
Transport/Working Mode Control
Slide this knob to TOP position (Working Mode) to operate the machine. Slide this knob to BOTTOM position
to move the machine and park the machine. The machine will not turn ON in this mode.
Warning! Keeping the knob in the top position (working mode) and moving the machine will damage the
brushes.
1
2
OFFON
BEFORE
RESET
WAIT
SECONDS
30
!
PRESS
Brush Contact Control
Brush contact with the oor is adjustable in 4 steps, contact is MINIMUM when the knob
is fully down and MAXIMUM when it is fully raised. This helps you to compensate for the
wear of brushes and also to control the scrubbing eect. If the machine does not move
when the handle is lowered, slide the transport/working mode knob up one step.
1
2
OFFON
BEFORE
RESET
WAIT
SECONDS
30
!
PRESS
1. Insert the two tubular handles into the bottom handle and secure them using
the knob by tightening lightly. Make sure that the handles are assembled
according to their marked position and the cable holding hooks are pointed
towards the rear.
2. Slide the electric cable retainer into the top portion of RH handle.
3. Fit the top handle over the tubular handles and secure them with washer and
screw (2 sets). Make sure that the label on the top handle is facing the front
of the machine. Now rmly tighten both knobs and screws. Insert the plastic
caps provided to cover the screws in the top handle.
4. Pass the free end of the pull cable through the plastic guide in the RH Handle.
Press and twist clockwise to rmly secure the cable end to the lid pump
housing.
5. Fix the solution tank rmly into the bottom handle by holding the top handle.
6. Rotate the knob to hold the solution tank.
7. The brushes are loosely packed in the machine for transit; therefore the brush
shafts must be tted before operating the machine. Push the shafts through
the brushes from the side of the machine. To remove brushes, push the
brush shaft out from the side of the machine using your ngers and pull it from
the other side.
8.The machine is now ready for use.
RIGHT
BOTTOM
REAR
LEFT
BOTTOM
REAR
Assembly
Controls

Tornado BR 18/1 MW Specifications

General

Brand	Tornado
Model	BR 18/1 MW
Category	Scrubber
Language	English
