13
Troubleshooting Table:
Problem Solution
No power, nothing works * Plug in cord
* Check for loose wiring
* Call Service
Brush does not rotate * Reset circuit breaker
* Activate brush switch
* Check for loose wiring
* Call Service
Poor water spray * Spray jets clogged - remove
and clean spray jets
* Check pump – remove spray jets
and check water flow
* Call Service
Vacuum motor runs but poor suction * Remove debris from vac shoe
* Recovery tank too full - drain tank
* Remove debris from suction hose
* Call Service
Vacuum motor will not run * Activate vacuum switch
* Check for loose wiring
* Call Service
Service Parts List:
P/N Description
02661 Wheel-10”
16091 Clamp-Hose (screw) 1-1/4”-2”
16620 Siphon Hose (1-1/2” X 23-1/2” Lg.)
19097 Filter-Vac Motor Intake
19119 Gasket-Vac Motor
19129 Access Cover-Tank
19154 Spray Nozzle1/8” (V-Jet)
19159 Brush Roller 17”
19233 Belt-Timing 150 X L X 3/8”
32178 Inline Strainer 3/8” NPT
32203 Kit-Pump w/Fittings
