Page #5 background image
5
2.3 Technical Parameter Description
2.4 Product Description
2.4.1 Product Structure Description
Model T6
Voltage 220-240V
Current 15.2
Motor 5HP(4KW)
Inverter 5HP(3.7KW)
Frequency 50/60HZ
Rotating Speed 0-1400RPM
Working Area 460MM
Grinding Disc 200MM*3
Water Tank 30L
Weight 135KGS
Dimension 970MM*460MM*800MM
