INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 3.2.1 /1
3. LOCATION & INSTALLATION
3.1 FLOOR PLANS
DECO 20a See figures in Para. 3.3.
DECO 26a See figures in Para. 3.4.
3.2 FLOOR LOCATION
− Take into account the dimensions of various options that you can attach
to the machine (bar feed tube, barfeeder, conveyor, equipment for long
parts, for deep drilling, etc.) because the floor plan shows the basic
machine equipment only.
− Arrange a barfeeder according to a particular bar feeding method.
− See your instructions:
INTERFACE SPECIFICATIONS FOR INSTALLATION OF STOCK TUBE
OR BARFEEDER
Δ Warning !
Spacing between the lathe and the barfeeder must be too close for
fingers to get in between and suffer injury.
3.2.1 Removing Transport Locks
What to do ? Notes
− Remove the wooden wedges
and ropes that hold various items
in place:
oil tank, chip pan, manipulator,
hatches
− Take down the yellow pieces
locking the frontwork unit and the
pickoff spindle:
See Fig. 306009f1 & 306009f2.
Z3 & Z4 axes
− Unscrew the yellow M8x60 screw
from the front of the vertical sup-
port:
The screw locks the part catching
manipulator. Put away the locking
pieces for possible use in future.
To Next Page
