INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 3.8.1 /23
3.8.1 Connecting TORNOS Autotransformer
1
Connect 60 Hz mains supply.
. Caution !
The autotransformer is located
outside the machine.
no
Autotransformer
TORNOS
Connecting Non-TORNOS
autotransformer, see para. below
Machine input
terminal box
L1
L2
L3
yes
Cut off mains supply.
50Hz ?
Mains
input
50 Hz
230V
230V
230V 400V
400V
500V 400V
500V
500V
200V
200V
200V
Machine input
terminal box
see fig. 106
L1
L2
L3
Mains
input
60 Hz
230V
230V
230V 460V
460V
500V 460V
500V
500V
200V
200V
200V
yes
no
2
Connect 50 Hz mains supply.
