INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 3.9 /25
3.9 CONNECTING BARFEEDER AND CHIP CONVEYOR
See Fig. 106 & 107.
Δ Danger !
Switch off (0 setting) and lock Main Switch QS0.
See also SAFETY REGULATIONS DECO 2000.
What to do ? Notes
− Disconnect the electric cabinet
(QS0 at 0, etc. as above)
Note :
See also your Instructions:
INTERFACE SPECIFICATIONS
FOR INSTALLATION OF
STOCK TUBE OR BARFE-
EDER
and
INTERFACE SPECIFICATIONS
FOR INSTALLATION OF CHIP
CONVEYOR.
− Connect the barfeeder over
Socket XS94.
− Connect the chip conveyor over
Socket XS38.
>>>
