INSTALLATION − DECO 20a / DEC0 26a / DECO 20e / DECO 26e
300561 en − 05/08 Chap. 3.7.1 /20
− Activate the circuit-breaker on the autotransformer terminal
box.
− Turn on Main Switch QS0, see Fig. 106.
− Check XS1 service socket voltage, see Fig. 106.
YES NO
YES
NO
2
1
Machine properly connected
− Turn off Main Switch QS0.
− Adjust voltage to TC1 transformer input,
see Fig
. 108.
− If voltage too high, connect to R,S,T 380.
− If voltage too low, connect to R,S,T 420.
− Turn off Main Switch QS0
− Adjust voltage to TC1 transformer input,
see Fig
. 108.
− If voltage too high, connect to R,S,T 440.
− If voltage too low, connect to R,S,T 480.
Connecting TORNOS Autotransformer,
continued
220V−240V
or American socket
100V−110V ?
50 Hz ?
