Toro 03678 - Pushing or Towing the Machine

g031851
Figure55
1.Fronttie-down
•Rear—eachsideofthemachineontherearframe
(Figure56)
g004555
Figure56
1.Reartie-down
PushingorTowingthe
Machine
Inanemergency,themachinecanbemoved
byactuatingthebypassvalveinthevariable
displacementhydraulicpumpandpushingortowing
themachine.
Important:Donotpushortowthemachinefaster
than3to4.8km/h(2to3mph)becauseinternal
transmissiondamagemayoccur.Thebypass
valvemustbeopenwheneveryoupushortow
themachine.
1.Thebypassvalveislocatedontheleftsideof
thehydrostat(Figure57).Rotatethebolt1-1/2
turnstoopenandallowuidtobypassinternally.
Note:Youcannowmovethemachineslowly
withoutdamagingthetransmission.
g003995
Figure57
1.Bypassvalve
2.Closethebypassvalvebeforestartingthe
engine.However,donotexceed7to11N∙m.(5
to8ft-lb)torquetoclosethevalve.
Important:Runningtheenginewiththe
bypassvalveopencausesthetransmission
tooverheat.
