Toro 04030 - Product Overview; Controls

ProductOverview
Figure12
1.Handle
5.Cuttingunit
2.Controlpanel6.Grassbasket
3.Engine7.Fueltank
4.Transportwheels
Controls
Figure13
1.Throttlecontrol
3.Service/parkingbrake
2.Traction&reeldrive
engagementlever
4.On/offswitch
ThrottleControl
Thethrottlecontrol(Figure13)islocatedonrearright
sideofcontrolpanel.Leverconnectstoandoperates
throttlelinkagetocarburetor.Enginespeedcanbe
variedfrom2400RPMto3600RPM.
TractionandReelDriveEngagement
Lever
Thetractionandreeldriveengagementlever(Figure13)
islocatedonfrontrightsideofcontrolpanel.Traction
leverhastwopositions:NeutralandForward.Pushing
leverforwardengagestractiondrive.
Thereeldriveleverhastwopositions:Engageand
Disengage.Movetopoflevertothelefttoengagereel
orbacktoneutraltodisengagereel.
Service/ParkingBrake
Theservice/parkingbrake(Figure13)islocatedonleft
frontsideofcontrolpanel.Pullingtheleverbackover
centerwillsettheparkingbrake.Brakemustbereleased
beforetractiondriveisengaged.
On/OffSwitch
Theon/offswitch(Figure13)islocatedontopof
controlpanel.MoveswitchtoOnpositiontostart
engineandOfftostopengine.
OperatorPresenceControl
Theoptionaloperatorpresencecontrolmustbeengaged
beforeengagingthetractionleverortheenginewillstop.
ChokeLever
Thechokelever(Figure14)islocatedonleftfrontof
engine.Leverhastwopositions:RunandChoke.Move
thechokelevertothehalf-openpositionwhenstarting
acoldengine.AfterenginestartsmovelevertoRun
position.
Figure14
1.Chokelever2.Fuelshut-offvalve
FuelShut-OffValve
Thefuelshut-offvalve(Figure14)islocatedonleft
frontofengine.Valvehastwopositions:Closedand
14
