Toro 04030 - Backlapping the Reel

2.Securebedbartoeachsideplatewithbedbarbolts
(jamnutsonbolts)and8washers.Anylonwasher
istobepositionedoneachsideofsideplateboss.
Placeasteelwasheroutsideeachofthenylon
washers.Torqueboltsto240-320in.-lb.
3.Tightenthejamnutuntiltheendplayisremoved
fromtheoutsidethrustwashers.Donotovertighten.
Note:Itisacceptablethattheinsidethrustwashers
onthecuttingunitmayremainloose.
4.Tightenspringtensionnutuntilspringiscollapsed,
thenbackoff1/2turn.
5.Adjustbedbar;refertoAdjustingtheBedknifeto
theReel.
BacklappingtheReel
1.Removeplugfromthereeldrivecoverontheleft
sideofreelassembly(Figure64)
Figure64
1.Reeldrivecoverplug
2.Inserta18mmsocketontohexangenutonleft
endofreelshaft.
3.BacklapaccordingtotheprocedureintheToro
SharpeningReelandRotaryMowersManual,Form
No.80-300PT.
Contactwiththereelorothermovingpartscan
resultinpersonalinjury.
•Stayawayfromthereelwhilebacklapping.
•Neveruseashorthandledpaintbrushfor
backlapping.PartNo.29-9100Handle
assemblycompleteorindividualpartsare
availablefromyourlocalAuthorizedToro
Distributor.
Note:Forabettercuttingedge,runaleacross
thefrontfaceofthebedknifewhenthelapping
operationiscompleted.Thiswillremoveanyburrs
orroughedgesthatmayhavebuiltuponthecutting
edge.
4.Reinstallplugwhenbacklapoperationiscompleted.
37
