Toro 04030 - Adjusting the Height of Cut

fromthefront,paralleltothebedknife.Aslightdrag
willbenotedasthepaperispulled.
Figure55
Note:Eachtimeadjustingscrewisrotatedoneclick
clockwise,thebedknifemoves.0007inchcloserto
reel.Donotovertightentheadjustingscrews.
5.Checkforlightcontactatotherendofreelusing
paperandadjustasrequired.
6.Afteradjustmentisaccomplished,checktoseeifreel
canpinchpaperwheninsertedfromthefrontandcut
paperwheninsertedatarightangletothebedknife
(Figure55).Itshouldbepossibletocutpaperwith
minimumcontactbetweenthebedknifeandthereel
blades.Shouldexcessivereeldragbeevidentitwill
beeithernecessarytobacklaporregrindthecutting
unittoachievethesharpedgesneededforprecision
cutting(seeTororeelsharpeningmanual).
AdjustingtheHeightofCut
Forheightsofcutgreaterthan.500",thehighheight
ofcutkitmustbeinstalled.
1.Loosenlocknutssecuringheight-of-cutarmsto
cuttingunitsideplates(Figure56).
Figure56
1.Rearrollerbracket3.Locknut
2.Height-of-cutarm
4.Adjustingscrew
2.Loosennutongaugebar(Figure57)andset
adjustingscrewtodesiredheight-of-cut.Distance
betweenbottomofscrewheadandfaceofbaris
height-of-cut.
Figure57
1.Gaugebar
3.Nut
2.Heightadjustingscrew
3.Hookscrewheadoncuttingedgeofbedknifeand
restrearendofbaronrearroller(Figure58).
