48VDC/12VDCConverter(Model04590)

g307998

Figure54

1.48VDC/12VDCConverter2.T1:PrimaryController

The48Vbatterypackandthe48VDC/12VDCconverterareusedtosupplythe

12VDCelectricalsystemwithpower.The48VDC/12VDCconverterislocated

undertherightsidecoverbelowtheT1:primarycontroller.

Testingthe48VDC/12VDCConverter

The48VDC/12VDCconverteranditscircuitwiringcanbetestedusingthe

InfoCentersplashscreen(batteryicon);refertoUsingtheInfoCenterDisplayfor

Troubleshooting(page3–39).Iftestingdeterminesthattheconverterandcircuit

wiringarenotfunctioningcorrectly,proceedwiththefollowingtestprocedure:

1.Parkthemachineonalevelsurface,lowerthecuttingunits,setthekey

switchtotheOFFpositionandremovethekeyfromtheswitch.

2.Removetherightsidecover.

3.Disconnectthe48VDC/12VDCconverterfromthemachinewireharness.

Checktheharnessconnectorsfordamageorcorrosionandcleanorrepair

asnecessary.Useamultimeter(VDCsetting)tocheckthemachinewire

harnessconnector.

LocationHarness

Connector

Wire

Color

Expected

Reading

ConnectorGraphic

1MainP073

Black/White

2MainP074Tan

48VDC

(nominal)

4.Connectthe48VDC/12VDCconvertertothemachinewireharness.Usea

multimeter(VDCsetting)tocheckthemachinewireharnessconnector(from

thebackoftheconnector).

Greensmaster®eTriFlex3360and3370

Page5–49

ElectricalSystem:TestingtheElectricalComponents

19239SLRevB
