Toro 07211 - Setup

17
Setup
Note: Determine the left and right side of the machine from the normal operating position.
Description Qty. Use
Fenders–Rear
Capscrew 5/16–18 x 1” lg.
Flatwasher .344” I.D.
Locknut 5/16–18
Capscrew 1/4–20 x 1” lg.
Flatwasher .281” I.D.
Locknut 1/4–20
Truss head screw
Locknut 3/8–16
2
4
4
4
12
12
12
6
6
Mount rear fenders on Model 07211TC only
Wheel Nut
Wheel–Front
Wheel Nut
Wheel–Rear
10
2
10
2
Mount wheels on Model 07211TC only
Steering wheel
Foam Seal
Washer
Nut
Cap
1
1
1
1
1
Install steering wheel on Model 07211TC only
Fenders–Front
Phillips screw
Washer
Locknut 10–24
2
14
14
14
Install front fenders on Model 07211TC only
ROPS
Capscrew 1/2–13 x 3” lg.
Locknuts 1/2–13
1
4
4
Mount ROPS on Model 07211TC only
Operator’s Manual (vehicle) 2 Read before operating the machine.
Parts Catalog 1
Registration Card 1 Fill out and return to Toro.
