Install Rear Fenders
(Model 07211TC only)
1. Loosen the locknuts and capscrews securing tail light
plates to right and left frame brackets (Fig. 1).
2. Pivot tail light plates rearward and tighten capscrews
and locknuts.
1
2
3
Figure 1
1. Tail light plate
2. Frame bracket
3. Tail light mounting bracket
3. Secure rear of each tail light plate to rear of frame
brackets with a 5/16–18 x 1” lg. capscrew, .281” I.D.
flatwasher and nut, as shown in figure 1.
4. On left side, remove (2) capscrews, washers and nuts
securing tail light mounting bracket to tail light plate
(Fig. 2).
1
2
Figure 2
1. Fender 2. Fender mounting bracket
5. Position a fender over each tail light plate, aligning
mounting holes.
6. On left side, loosely secure tail light mounting bracket,
rear of fender and tail light plate together with (2)
capscrews, washers and nuts, previously removed.
7. On right side, secure rear of fender to tail light plate
with (2) 1/4–20 x 1” lg. capscrews, .281” I.D.
flatwashers and nuts
8. Loosely secure front of each fender mounting bracket to
frame with a 1/4–20 x 1” lg. capscrew and locknut.
9. Loosely secure side of each fender to frame (3) 3/8–16
x 1” lg. truss head screws and locknuts.
Note: Capscrews securing fronts of fenders to mounting
brackets may have to be loosened to align all mounting
holes.
10. Tighten all fasteners.
Install Wheels
(Model 07211TC only)
1. Remove and discard fasteners securing wheels.
2. Mount wheels and torque nuts to 55–75 ft-lb.
1
2
Figure 3
1. Wheel 2. Wheel nut
Install Steering Wheel
(Model 07211TC only)
1. Remove jam nut from steering shaft. Slide foam seal,
steering wheel and washer onto steering shaft.
2. Secure steering wheel to shaft with jam nut and tighten
it to 10–15 ft-lb.
