FuelSystem

Maintenance

FuelSystem

FuelLinesandConnections

ServiceInterval:Every400hours/Yearly(whichever

comesrst)

Every1,000hours/Every2years

(whichevercomesrst)

Checklinesandconnectionsevery400hoursoryearly,

whichevercomesrst.Inspectfordeterioration,

damage,orlooseconnections.

FuelFilter

ServiceInterval:Beforeeachuseordaily

Every400hours

Drainwaterorothercontaminantsfromfuellter/water

separatordailybylooseningdrainplug(Figure51)on

ltercanister.Tightenplugafterdraining.

1.Raisebed(ifsoequipped)andplacesafetysupport

onextendedliftcylindertoholdupbed.

2.Placeacleancontainerunderfuellters.

Figure51

1.Fuellter

3.LoosenR–clampssecuringltertoframe.

4.Removeclampsecuringfuelltertofuellines.

5.Installnewfuelltertofuellineswithclamps

previouslyremoved.Filtermustbemountedso

arrowpointstowardcarburetor.

ElectricalSystem

Maintenance

Fuses

Thefusesforthemachine’selectricalsystemarelocated

underthecenterofthedashpanel.

Figure52

1.Fuses

Figure53
