EngineMaintenance
ServicingtheAirCleaner
ServiceInterval:Every25hours—Removetheair-cleaner
coverandcleanoutthedebris.
Every100hours—Changetheair-cleanerlter(more
frequentlyindustyordirtyconditions).
Inspecttheaircleanerandhosesperiodicallytomaintain
maximumengineprotectionandtoensuremaximumservice
life.Checktheair-cleanerbodyfordamage,whichcould
possiblycauseanairleak.Replaceadamagedair-cleanerbody.
Inspectandchangetheair-cleanerlterasdescribedinthe
followingprocedure:
1.Releasethelatchesontheaircleanerandpullthe
air-cleanercoverofftheair-cleanerbody(Figure43).
Figure43
1.Air-cleanercover2.Filter
2.Squeezethedustcapsidestoopenitandknockthe
dustout.
3.Gentlyslidethelteroutoftheair-cleanerbody
(Figure43).
Note:Avoidknockingthelterintothesideofthe
body.
Note:Donotattempttocleanthelter.
4.Inspectthenewlterfordamagebylookingintothe
lterwhileshiningabrightlightontheoutsideofthe
lter.
Note:Holesinthelterwillappearasbrightspots.
Inspecttheelementfortears,anoilylm,ordamageto
therubberseal.Ifthelterisdamageddonotuseit.
Topreventenginedamage,alwaysoperatetheengine
withtheairlterandcoverinstalled.
Takespecialcaretokeepparticulatesfromdropping
intothecleanareasoftheair-lterhousing.
5.Carefullyslidethelteroverthebodytube(Figure43).
Note:Ensurethatitisfullyseatedbypushingonthe
outerrimofthelterwhileinstallingit.
6.Installtheair-cleanercoverwiththesidefacingup,and
securethelatches(Figure43).
ChangingtheEngineOiland
Filter
ServiceInterval:Aftertherst50hours
Every200hours
Engine-oilquantity:3.2L(3.4USqt)(withalter)
Engine-oiltype:DetergentengineoilAPISJorhigher
Engine-oilviscosity:10W-30;Chooseanengine-oil
viscosityaccordingtotheambient-airtemperaturetothe
tableinFigure44.
G016095
Figure44
1.Raisethebed(ifequipped),andplacethesafetysupport
ontheextended-liftcylindertoholdupthebed.
2.Removethedrainplugandlettheoilowintoadrain
pan(Figure45).
G021292
1
2
Figure45
1.Engine-oil-drainplug
2.Engine-oillter
