youwillnotneedit.Theexcessskiddingofthedragmatcan
causecosmeticdamagetotheedges.
UsingtheDragMatCarrier
Thedrag-matcarrierisdesignedtohavethetractionunit
adapterinthelowestpositionwhileinuse.Whenlowered,
thepivotassemblyshouldbeapproximatelyinthecenterof
theslot(Figure13).
Note:Donotusethecoconut-bermatinheavy,wet
conditions.Thematwillllupwithmaterialandnotwork
properly.
Note:Usingthesteelmatisnotrecommendedongolf
greens.
Figure13
1.Slot
2.Attachmentadapter
AdjustingtheTransport
Position
Completethefollowingproceduretoincreasetheheightof
thedrag-matcarrierwhentransporting:
1.Lowerthedrag-matcarrieraslowaspossible.
2.Disconnectthechainsfromtheliftarmsandconnect
theminadifferentlink.
Note:Toensureproperoperationofthedrag-matcarrier,
returnthechainsmusttotheoriginalslackpositionbefore
beginningoperation.
Removingthe
Drag-Mat-CarrierSystem
1.Pivotthelockinglevertotheleft(Figure14).
2.Lowerthetraction-unitadapter.
3.Grabthehandleliftandtilttheattachmentbackonto
theattachment(Figure14).
Figure14
1.Lockinglever2.Handle
Note:Iftheattachmentadapterbecomesstucktothe
traction-unitadapter,insertaprybar/screwdriverintothepry
slottodisengagetheparts(Figure15).
Figure15
1.Pryslot
